9985-OM (V1.18) 9985 PRODUCT MANUAL 3-1
Chapter 3
Chapter 3
Operating Instructions
Overview
This chapter contains the following information:
• Control and Display Descriptions (p. 3-1)
• Accessing the 9985 Card via Remote Control (p. 3-6)
• Checking Card Information (p. 3-8)
• Ancillary Data Line Number Locations and Ranges (p. 3-9)
• 9985 Function Submenu List and Descriptions (p. 3-10)
• Troubleshooting (p. 3-67)
Control and Display Descriptions
Note: When you are familiar with the card functions and controls described in this
chapter, please go to the Support>Documents>Reference Guides link at
www.cobaltdigital.com for Fusion3G
® application notes covering comprehen-
sive setup of practical processing applications.
This section describes the user interface controls, indicators, and displays
(both on-card and remote controls) for using the 9985 card. The 9985
functions can be accessed and controlled using any of the user interfaces
described here.
The format in which the 9985 functional controls, indicators, and displays
appear and are used varies depending on the user interface being used.
Regardless of the user interface being used, access to the 9985 functions (and
the controls, indicators, and displays related to a particular function) follows a
general arrangement of Function Submenus under which related controls can
be accessed (as described in Function Submenu/Parameter Submenu
Overview below).
If you are already familiar with
using DashBoard or a Cobalt
Remote Control Panel to control
Cobalt cards, please skip to
9985 Function Submenu List
and Descriptions (p. 3-10).
