Operating Instructions
9284 Function Submenu List and Descriptions
9284 Function Submenu List and Descriptions
Table 3-1 individually lists and describes each card function submenu (“tab”)
and its related list selections, controls, and parameters. Where helpful,
examples showing usage of a function are also provided.
Note: All numeric (scalar) parameters displayed on DashBoard™ can be changed
using the slider controls,
arrows, or by numeric keypad entry in the corre-
sponding numeric field. (When using numeric keypad entry, add a return after
the entry to commit the entry.)
Note: For any text entries made using the card GUI (unless accompanied by a Save
button), commit the changes using the card Refresh button.
On DashBoard™ itself and in Table 3-1, the function submenu items are
organized using tabs as shown below.
The table below provides a quick-reference to the page numbers where each
function submenu item can be found.
Note: Host Settings and Panel Settings tabs are for dedicated serial communica-
tion control and are reserved for this product’s release.
Function Submenu Item Page
Module Settings 3-10
I/O Settings 3-12
Salvos 3-14
Control 3-15
