9284-OM (V1.3) 9284 PRODUCT MANUAL 1-23
Introduction
Technical Specifications
Table 1-2 Technical Specifications
Item Characteristic
Part number, nomenclature 9284 3G/HD/SD-SDI 8x4 Video Routing Switch
Installation/usage environment Intended for installation and usage in frame meeting openGear
modular system definition.
Power consumption < 10 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
Switch Panel communication Serial; RS-232 and/or RS-485 (reserved)
Indicators Card edge indicators as follows:
• Power indicator
• Ref lock indicator
Serial Digital Video Input Number of Inputs:
Eight 3G/HD/SD-SDI BNC Source Inputs
Data Rates Supported:
SMPTE 424 HD-SDI: 2.97 Gbps
SMPTE 292 HD-SDI: 1.485 Gbps or 1.485/1.001 Gbps
SMPTE 259M-C SD-SDI: 270 Mbps
Impedance:
75 Ω terminating
Equalization (3G, HD):
328 ft (100 m) Belden 1694A for SMPTE 292-2008, 424M-2006
Equalization (SD):
1000 ft (305 m) Belden 1694A for SMPTE 259M-2008
Return Loss:
> 15 dB at 5 MHz – 1.485 GHz
> 10 dB at 1.5 GHz – 3.0 GHz
