Speedhut SST Shift-Light - Manual (Page 3)

You can set up your shift light brightness for both day and night conditions. The shift light will retain this setting
in memory. The white wire senses whether the shift light is in night or day mode. If voltage is present on white
wire, it is assumed your setting the night brightness mode. If no voltage is present, you are setting the day
brightness.
1. Press and hold button for 2 seconds to select LED menu.
2. Current brightness is shown on LED screen as a number, and shift light LEDs will be lit to show current
brightness.
0= off condition - 4 = maximum brightness
3. Toggle through brightness setting using buttons.
4. At desired brightness setting let shift light time out for 5 seconds to save the setting. LEDs will flash 2 times
on exit of menu.
5. Repeat procedure for both day and night condition.
Your shift light will display current engine RPM in LED display while in operation. You can turn this setting on or
off.
Note: Engine RPMs < 9,999 will show as this example
8.35 = 8350 RPM
Note: Engine RPMs >10,000 will show as this example
12.5 = 12,500 RPM
1. Press and hold button for 2 seconds to select dsp menu.
Shift LED brightness settings
LED display on/off setting.
WARRANTY - Speedhut inc. warrants to the consumer for a period of 5 years from the date of purchase that the product will be free from defects in materials or workmanship.
Speedhut warrants to the consumer for a "LIFE-TIME" that the gauge circuit board will be free from defects in materials or workmanship. Please contact Speedhut service dept.
If you have a problem with this gauge. [email protected]
