Speedhut Edge Attitude Pillar, Pod, and Mount User Manual

Page 2

www.Speedhut.com Need help? Contact us: Speedhut Inc. 165 North 1330 West B2 Orem, Utah 84057 or call 801-221-1460

Model #13002 are designed to fit 99-06 Ford Super Duty (2 velcro strips)

Installation Instructions: Ford Super Duty 99-06 overhead console mount

STEP ONE: Attach the two Velcro pieces together. Peel back strip to expose adhesive from one side and attach to the

recessed area of the mount where the Attitude fits.

STEP TWO: Expose adhesive and install Attitude in mount. Press firmly to engage adhesive to back of Display.

(Do not press on LCD)

STEP THREE: Apply Velcro to rear of Pod.

STEP FOUR: Clean window area where Velcro attaches.

STEP FIVE: Peal backing off Velcro.

Note: In step 6 be careful not to let Velcro touch windshield.

STEP SIX: Insert top edge of pod back into the space between the windshield and the metal roof edge, located under

the headliner.

STEP SEVEN: Feed wiring under headliner for several inches and slide pod into position above rear view mirror.

STEP EIGHT: Push pod firmly up against head liner.

STEP NINE: With pod firmly against head liner, press bottom of pod against windshield, apply firm pressure to bond

Velcro to window.

Note: Hold firm pressure for at least one minute. Continue running wiring under headliner and down a-pillar.
