Speedhut SST-MAX OBDII Shift-Light (CAN Protocol) - Manual (Page 3)

1. Press and hold a button for 2 seconds while viewing the current RPM*. The Peak Recall menu will be displayed.
2. Toggle through to to select a gear.
Launch RPM Menu
LED Display Setting
The shift-light will display current engine RPM or current gear on the LED display while in operation. If desired you can turn this feature off.
1. Select the
3. Press and hold a button to show the peak RPM for the selected gear, release the button to continue toggling.
1. To clear all peak recall memory, press and hold a button for 2 seconds. Display will blink indicating that the memory has been cleared.
*
The LED display settings can be chnanged to display one of these options - Current RPM, Current Gear, or the display can be turned off.
Press and hold a button for 2 seconds while any of these options are displayed to enter the Peak Recall menu.
Clear all Peak Recall Memory
Engine RPM Peak Recall
The shift-light LED display by default will display the current engine RPM while in use.
Note: Engine RPM is displayed as this example: 8.35 = 8350 RPM
Shift-Light LED brightness settings
You can set the shift light LED brightness. The shift light will retain this setting in memory.
1. Select the
The SST-MAX Shift-Light Launch feature allows you to set a predetermined launch RPM point.
200 RPM below of the Launch point the shift-light will be off. 200 RPM above of the Launch point the shift-light will blink.
While in the Launch RPM zone the shift-light is steady on to indicate that you are on the correct RPM.
Launch feature is automatically active when vehicle is not moving and the shift light is powered on.
WARRANTY - Speedhut inc. warrants to the consumer for a period of 5 years from the date of purchase that the product will be free from defects in materials or workmanship.
Speedhut warrants to the consumer for a "LIFE-TIME" that the product circuit board will be free from defects in materials or workmanship.
Please contact Speedhut service department If you have a problem with this gauge.
Speedhut Inc. 165 North 1330 West B2, Orem, Utah 84057 | [email protected] | (801) 221-1460 (9am - 5pm MST)
Additional Features and Operating Instructions
1.Turn on power to the Shift-light by starting up the vehicle (or plug it into the ODBII port).
2. To access most menus follow this procedure below.
A quick press
enters menu mode
A quick press
toggles menus
Press hold 2 secs
to select menu
The SST-MAX OBDII Shift-light features an easy to use LED display menu. The LED display can also display your engine RPM.
menu option, press and hold a button for 2 seconds. Current setting will be displayed. 1. Select the
2. Toggle through 1.00 to 9.99.
2. Press a button to toggle between
3. To save the setting, do not press a button for 5 seconds.
menu option, press and hold button for 2 seconds. Current display option will be displayed.
2. Toggle through brightness setting using buttons.
OFF = Turns off the shift-light LEDs
1-4 = Indicates a brightness level
3. At desired brightness setting let shift light time out for 5 seconds to save the setting. LEDs will flash 2 times on exit of menu.
menu option, press and hold a button for 2 seconds. Current brightness setting will be displayed.
, , , . and
- LED display will show current engine RPM while in operation
- LED display will show current gear number while in operation
- LED display will show current Speed in MPH
- LED display will be turned off
Note: Engine RPM will show as this example: 8.35 = 8350 RPM
Note: Engine RPM will show as this example: 8.35 = 8350 RPM
Power Note: There is no need to disconnect the shift light when not in use. The SST-MAX Shift-light will automatically go into a power saving mode when the
vehicle is off. When the engine is started up the Shift-light will instantly be powered on and ready to use.
3. To disable the launch feature - set launch RPM to 9.99
,
- LED display will flip the displayed information upside down.
