6-16
2000-800-02 Motorized Loader
DIAL , BEAM OR SCREW DRIVER MODE:
( This mode is used to check or test the Dial wrenches ).
· Setup the Torque Tester:
** Mode:- Peak or TRACK
** Select an appropriate Unit (ft-lb, Nm, etc.)
· Setup the Motorized Control Box:
** Press F1 key to select Dial Mode.
The LCD display reads:
Press RUN key to start Dial Mode:
The LCD Display reads:
Use the cursor keys Up, Down, Left, Right to enter
Target Value, Number of Cycles and Direction.
Typically, the Target Value in Dial Mode should be
about -5% to -10% of the required torque.
Example :
For Dial wrench check at 55 ft-lb, set Target Value at 50 ft-lb.
Press RUN or Enter key to accept all Parameters.
NOTE :
The default Setup upon Power up is :
* Target :
7% of Transducer.
* Cycle: 00001
* Dir: CW
The MCB does NOT accept any Target value that exceeds
Max Transducer Range.
*** MODE (Dial) ***
Press Run to Start
*** DIAL MODE ***
Target Cycle Dir
50.00 ft-lb 00005 CW
