3-2
Setup and Programming
Setting Up the Motorized Control Loader System
1. Position the roll cabinet on a level floor and lock the
wheels.
2. Mount the indicator stand, part number 2000-111-0, to
the Loader.
3. Mount the 2000-810-01 Indicator to the stand.
4. Connect the cables between the Indicator, Motorized
Control Box and Power Amplifier Box.
(Refer to chapter 6)
5. Install the appropriate MULTITEST transducer to the
Loader drive.
6. Install two (2) quick release pins, part number 2000-195-
12.
7. Connect the transducer cable, part number 2000-900-
120, between the Indicator and transducer.
8. Select the appropriate AC voltage input at the rear of the
Indicator. Connect the AC power cables to the Indicator
and the Power Amplifer Box. For additional information
refer to Chapter 6—Loader Rear Panel Controls.
9. Install the safety shield to the front of the Loader.
10. Install the reaction pins into the reaction slide on the
Loader.
For testing procedures refer to Chapter 4—Using
the Torque Tester.
Various fixtures, cables and adaptors are available for testing
the most common compression or tension gauges. Ask your
CDI sales representative for assistance.
