6-6
2000-800-02 Motorized Loader
Ball Handle Adaptor
Wrenches featuring a ball handle are fixtured using the ball
handle reaction adaptor shown in Figure 6-3. Install the
adaptor onto the reaction slide using both reaction pins. Fix the
adaptor height with the threaded knob.
Figure 6-3: Ball Handle Adaptor
