2-10
Functional Description and Specifications
Display Resolution for Transducers in Force Mode
Display Resolution for Transducers in Torque Mode
MULTITEST torque/force transducers can withstand an overload
of 110% of full range. The 2000-810-01 Indicator alarms,
(audible beep and display "OVER" red LED) at 110% of rated
capacity.
To protect the tool under test or serve as a fastener installation,
torque preset alert, the 2000-810-01 produces a constant
audible tone when the input torque/force exceeds the SET LOW
limit. It then produces a pulsating tone when the input
torque/force exceeds the SET HIGH limit.
2000-810-01 ignores inputs less than 0.1% of full range in
TRACK mode, 2% in PEAK HOLD mode, 7% in FIRST PEAK
and POWER TOOL modes. With the 4-in-1 transducer, 2000-
810-01 ignores inputs less than 2% of full range after scan
select.
mkg cmkg ft lb in lb in oz Nm dNm cNm
2000-5-02 .00003 .003 .0002 .002 .04 .0003 .003 .03
2000-6-02 .0001 .01 .0008 .01 .2 .001 .03 . 3
2000-65-02 .0003 .03 .002 .03 .5 .003 .03 . 3
2000-7-02 .001 .1 .006 .08 1.2 .009 .09 . 9
2000-8-02 .002 .2 .016 .2 3.2 .02 .2 2
2000-10-02 .004 .4 .03 .3 5 .03 .3 3
2000-11-02 .007 .7 .05 .6 10 .07 .7 7
2000-12-02 .016 1.6 .12 1.4 n/a .16 1.6 16
2000-13-02 .03 3 .2 3 n/a .3 2.7 n/a
2000-14-02 .05 5 .4 5 n/a .5 5 n/a
2000-400-02 .0001 .01 .0008 .01 .2 .001 .03 . 3
(4-in-1) .001 .1 .006 .08 1.2 .009 .09 . 9
.002 .2 .016 .2 3.2 .02 .2 2
.007 .7 .05 .6 10 .07 .7 7
N dN lbf ozf kp gf
2000-7-02 03 .3 .007 .1 .003 3
2000-8-02 .08 .8 .02 .3 .008 8
2000-10-02 .1 1 .02 .4 .01 10
2000-11-02 .2 2 .05 .8 .02 n/a
2000-12-02 .5 5 .12 2 .05 n/a
2000-13-02 .9 9 .2 3 .1 n/a
2000-14-02 1.8 18 .4 6 .2 n/a
