6-14
2000-800-02 Motorized Loader
If the Loader is not in the Home Position, the Display shows:
Make sure there is no wrench in Loader.
Press RUN key to start Homing.
The LCD display then reads:
Place wrench onto Loader.
Press RUN key to Start.
The motor starts applying force to the handle
of the Torque Wrench.
The MCB controls the Motor to increase the torque
until the Tester captures the first peak. An audio alert
is sounded when the target torque is reached.
The Motor reverses the direction after the wrench clicks.
The MCB continues until all 5 cycles are completed.
*** CLICK MODE ***
Put wrench in Loader
Then Hit Run.
*** CLICK MODE ***
Make sure there is
no wrench in Loader
Then hit Run
*** CLICK MODE ***
Moving to home Position
001 Sec
*** CLICK MODE ***
Target: 050.00 ft-lb
Cycle:
1/5
Speed: 100% (Motor)
*** CLICK MODE ***
Target:
050.00 ft-lb
Cycle: 1/5
Target Reached
*** CLICK MODE ***
Target: 050.00 ft-lb
Cycle:
1/5
Backing up %
