3. Foundation Requirements
14 PNEG-1510 Top Dry 24', 30' and 36' Manual Batch
Frost Free Foundation Top Dry Bins
Diameter of Bin: 24'
Corrugation : 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (Ft.)
Length #6
Bar (Ft.)
Total Cu. Yds.
Concrete
6 1'-1" 2 12'-9" 900 600 200 13
7, 8 1'-9" 2 12'-9" 900 600 200 15
9, 10 2'-6" 3 13'-2" 900 600 400 18
Diameter of Bin: 30'
Corrugation : 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (Ft.)
Length #6
Bar (Ft.)
Total Cu. Yds.
Concrete
6 1'-2" 2 15'-9" 1400 900 200 19
7, 8 1'-10" 2 15'-10" 1400 900 200 21
9, 10 2'-8" 3 16'-1" 1400 900 500 25
11 3'-8" 4 16'-5" 1400 900 700 29
Diameter of Bin: 36'
Corrugation : 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4
18" x 18" Grid (Ft.)
Length #6
Bar (Ft.)
Total Cu. Yds.
Concrete
6 1'-3" 2 18'-9" 2000 1300 300 26
7, 8 2'-0" 2 18'-11" 2000 1300 400 30
9, 10 2'-10" 3 19'-0" 2000 1300 600 33
11, 12 3'-11" 4 19'-6" 2000 1300 900 39
