PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual

31

6. Vision Touch Screen Display

Boot Screen

1. With the Power switch ON, pushing the START initiates the Vision computer.

2. The boot screen has four (4) “buttons”.

(See Figure 6A.)

3. The Start Dryer button enters the Default Operation screen.

Figure 6A

NOTE: See PNEG-1456 for vision touch screen display details.

Buttons used to
update software. (See
PNEG-1506 Vision
programming manual.)
