4. Specifications
PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual
15
FFI Specifications
Figure 4C
1 Fan CFAB Specifications
1
Actual discharge rate is controlled by meter roll speed adjustment, at 5% to 100% of maximum rate.
2
Excludes auxiliary load and unload conveyor equipment.
CFAB 150
8'
CFAB 190
10'
CFAB 270
12'
CFAB 320
14'
CFAB 370
16'
CFAB 400
18'
CFAB 460
20'
CFAB 511
22'
CFAB 601
26'
Total Holding Capacity (Bushels)
173
216
294
357
436
509
565
622
735
Grain Column Holding Capacity (Bushels)
149
186
257
300
376
414
460
506
598
Fans
28"
10-13 HP
28"
10-13 HP
36"
15 HP
40"
15 HP
40"
15 HP
42"
20 HP
42"
25 HP
42"
30 HP
42"
40 HP
Top Auger
8" Dia.
1.5 HP
8" Dia.
2 HP
8" Dia.
2 HP
8" Dia.
5 HP
8" Dia.
5 HP
8" Dia.
5 HP
8" Dia.
7.5 HP
8" Dia.
7.5 HP
8" Dia.
10 HP
Capacity (BPH)
680
925
1150
1800
2800
2800
2800
2800
2800
Bottom Auger
8" Dia.
1 HP
8" Dia.
1.5 HP
8" Dia.
2 HP
8" Dia.
3 HP
8" Dia.
3 HP
8" Dia.
3 HP
8" Dia.
5 HP
8" Dia.
5 HP
8" Dia.
7.5 HP
Meter Roll Drive
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
SCR,
3/4 HP
Capacity - Maximum Rate
1
(BPH)
1120
1400
1680
1960
2240
2520
2800
3080
3640
Electrical Load (Fans, Top and Bottom Augers
2
)
380 Volt, 50 Hz, 3 Phase
23
30
30
32
40
46
61
69
91
2 Fan CFAB profile
C2100A Profile
1 Fan CFAB profile
