4. Specifications
16 PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual
2 Fan CFAB Specifications
1 Actual discharge rate is controlled by meter roll speed adjustment, at 5% to 100% of maximum rate.
2 Excludes auxiliary load and unload conveyor equipment.
C2100A Specifications
1 Actual discharge rate is controlled by meter roll speed adjustment, at 5% to 100% of maximum rate.
2 Excludes auxiliary load and unload conveyor equipment.
CFAB 510
22'
CFAB 600
26'
Total Holding Capacity (Bushels) 622 735
Grain Column Holding Capacity (Bushels) 506 598
Fans 36" 15 HP (2) 40" 20 HP (2)
Top Auger 8" Dia. 7.5 HP 8" Dia. 10 HP
Capacity (BPH) 2800 2800
Bottom Auger 8" Dia. 5 HP 8" Dia. 7.5 HP
Meter Roll Drive SCR, 3/4 HP SCR, 3/4 HP
Capacity - Maximum Rate
1
(BPH) 3080 3640
Electrical Load (Fans, Top and Bottom Augers
2
)
380 Volt, 50 Hz, 3 Phase 69 109
C2120A
14'
C2122A
16'
C2125A
18'
C2130A
20'
C2132A
22'
C2140A
26'
Total Holding Capacity (Bushels) 375 436 490 544 599 708
Grain Column Holding Capacity (Bushels) 322 376 415 460 517 600
Fans
28" 10-13 HP/
28" 10-13 HP
28" 10-13 HP/
36" 15 HP
28" 10-13 HP/
36" 15 HP
28" 10-13 HP/
40" 20 HP
28" 10-13 HP/
42" 20 HP
28" 10-13 HP/
42" 25 HP
Top Auger 8" Dia. 5 HP 8" Dia. 5 HP 8" Dia. 5 HP 8" Dia. 7.5 HP 8" Dia. 7.5 HP 8" Dia. 10 HP
Capacity (BPH) 1800 2800 2800 2800 2800 2800
Bottom Auger 8" Dia. 3 HP 8" Dia. 3 HP 8" Dia. 3 HP 8" Dia. 5 HP 8" Dia. 5 HP 8" Dia. 7.5 HP
Meter Roll Drive SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP
Capacity - Maximum Rate 1 (BPH) 1960 2240 2520 2800 3080 3640
Electrical Load (Fans, Top and Bottom Augers 2 )
380 Volt, 50 Hz, 3 Phase 50 56 56 63 69 87
