4. Specifications
PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual 27
All Stack Specifications (Continued)
Figure 4L
NOTE: All dimensions are in mm.
1. A 12" thick reinforced concrete foundation and 16" pedestal (min.) are required. See bulletin
FL-02-2 for details. 32" Thick pedestal required for heat reclaimer option. (See bulletin FL-03-2
for details.)
2. Approximate location of standard service platform shown. See bulletin SP-02-2 for details.
For information on optional catwalk, see bulletin CATH-01-5.
3. For safety cage information, refer to bulletin SC-01-2.
A B C D E 1 F G H J K L N
14'
7048.5
(23'-1-1/2")
660.4
(2'-2")
4267.2
(14'-0")
1422.4
(4'-8")
406.4
(16" Min.)
3403.6
(11'-2")
1466.85
(4'-9-3/4")
203.2
(0'-8")
2438.4
(8'-0")
914.4
(3'-0")
7251.7
(23'-9-1/2")
1930.4
(6'-4")
18'
8267.7
(27'-1-1/2")
660.4
(2'-2")
5486.4
(18'-0")
1422.4
(4'-8")
406.4
(16" Min.)
3403.6
(11'-2")
1466.85
(4'-9-3/4")
203.2
(0'-8")
2438.4
(8'-0")
914.4
(3'-0")
7251.7
(23'-9-1/2")
1930.4
(6'-4")
20'
8877.3
(29'-1-1/2")
660.4
(2'-2")
6096.0
(20'-0")
1422.4
(4'-8")
406.4
(16" Min.)
3403.6
(11'-2")
1466.85
(4'-9-3/4")
203.2
(0'-8")
2438.4
(8'-0")
914.4
(3'-0")
7251.7
(23'-9-1/2")
1930.4
(6'-4")
22'
9486.9
(31'-1-1/2")
660.4
(2'-2")
6705.6
(22'-0")
1422.4
(4'-8")
406.4
(16" Min.)
3403.6
(11'-2")
1466.85
(4'-9-3/4")
203.2
(0'-8")
2438.4
(8'-0")
914.4
(3'-0")
7251.7
(23'-9-1/2")
1930.4
(6'-4")
26'
10706.1
(35'-1-1/2")
660.4
(2'-2")
7924.8
(26'-0")
1422.4
(4'-8")
406.4
(16" Min.)
3403.6
(11'-2")
1466.85
(4'-9-3/4")
203.2
(0'-8")
2438.4
(8'-0")
914.4
(3'-0")
7251.7
(23'-9-1/2")
1930.4
(6'-4")
H
L
E
B C
A
D
L
J
K
N
F
G
4267.2 (14'-0")
812.8 (2'-8")-REAR SAFETY CAGE
SEE NOTE 3
2362.2 (7'-9")-SAFETY
PLATFORM
3962.4 (13'-0")-OPTIONAL
CATWALK
SEE
NOTE 2
SEE
NOTE 1
