4. Specifications
18 PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual
Single Module GSI Transport and Installation Dimensions
NOTE: All dimensions are in mm.
Values are Valid for Transportation of Stack Modules
Dryer
Basket
A B C D E F G H
Transport
Height
Installed
Width
Installed Height
Height w/o
Wet Bin
Frame
Width
Transport
Width
Installed
Length
Transport
Length Wet
Bin
Standard
Top
1108T
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
4622.8
(15' 2'')
5232.4
(17' 2'')
1112
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
5842.0
(19' 2'')
6451.6
(21' 2'')
1114
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
6451.6
(21' 2'')
7061.2
(23' 2'')
1116
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
7061.2
(23' 2'')
7670.8
(25' 2'')
1118
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
7670.8
(25' 2'')
8280.4
(27' 2'')
1120
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
8280.4
(27' 2'')
8890.0
(29' 2'')
1122
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
8890.0
(29' 2'')
9499.6
(31' 2'')
1126
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
10109.2
(33' 2'')
10718.8
(35' 2'')
1214
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
6451.6
(21' 2'')
7061.2
(23' 2'')
1216
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
7061.2
(23' 2'')
7670.8
(25' 2'')
1218
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
7670.8
(25' 2'')
8280.4
(27' 2'')
1220
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
8280.4
(27' 2'')
8890.0
(29' 2'')
1222
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
8890.0
(29' 2'')
9499.6
(31' 2'')
1226
4089.4
(13' 5'')
2438.4
(8')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
10109.2
(33' 2'')
10718.8
(35' 2'')
1214S
4089.4
(13' 5'')
2641.6
(8' 8'')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
6451.6
(21' 2'')
7061.2
(23' 2'')
1218S
4089.4
(13' 5'')
2641.6
(8' 8'')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
7670.8
(25' 2'')
8280.4
(27' 2'')
1220S
4089.4
(13' 5'')
2641.6
(8' 8'')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
8280.4
(27' 2'')
8890.0
(29' 2'')
1222S
4089.4
(13' 5'')
2641.6
(8' 8'')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
8890.0
(29' 2'')
9499.6
(31' 2'')
1226S
4089.4
(13' 5'')
2641.6
(8' 8'')
4419.6
(14' 6'')
3962.4
(13')
3581.4
(11' 9'') 1955.8
(6' 5'')
2438.4
(8')
10109.2
(33' 2'')
10718.8
(35' 2'')
