Printronix PrintCart User Manual
Page 18
18
Chapter
2
PrintCart Layout
Figure 8. Power Pallet Features and Safety Devices (120V)
Inverter Setup
Switches
Inverter Display
Indicator
External Display
Panel Connector
Main Inverter
Power/Mode Switch
AC Output GFCI
Grounding Lug
(AC)
Negative Battery
Cable Input
Positive Battery
Cable Input
Battery Charger
Circuit Breaker (8A)
Main AC Input Power
Circuit Breaker (15A)
