l
1 x closing cap ½ NPT, 1 x blind stopper
½ NPT
, 1 x blind stopper M16 x 1.5 or
optionally 6) 1 x plug M12 x 1 for external
indicating and adjustment unit
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; 1 x blind stopper M16 x 1.5
or optionally
7) 1 x plug M12 x 1 for external
indicating and adjustment unit
Spring-loaded terminals for wire cross-section
-
Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
-
Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Electromechanical data - version IP 66/IP 68 (1 bar)
Cable entry
-
Single chamber housing 1 x IP 68 cable gland M20 x 1.5; 1 x blind stopper
M
20 x 1.5
-
Double chamber housing 1 x IP 68 cable gland M20 x 1.5; 1 x blind stopper
M
20 x 1.5; 1 x blind stopper M16 x 1.5
Connection cable
-
Wire cross-section 0.5 mm² (AWG 20)
-
Wire resistance < 0 .036 Ω/m
-
Tensile strength < 1200 N (270 lbf)
-
Standard length 5 m (16.4 ft)
-
Max. length 180 m (590.6 ft)
-
Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F)
-
Diameter approx. 8 mm (0.315 in)
-
Colour - standard PE Black
-
Colour - standard PUR Blue
-
Colour - Ex-version Blue
Indicating and adjustment module
Voltage supply and data transmission through the sensor
Indication LC display in dot matrix
Measured value indication
-
Number of digits 5
-
Size of digits W x H = 7 x 13 mm (sensors with software ≥ 4.0.0,
hardware ≥ 2.0.0)
W x H = 5 x 8 mm (sensors with software ≤ 3.99,
hardware < 2.0.0)
6) Only with Ex d version
7) Only with Ex d version
70 VEGAPULS 61 • Approval according to LPR radio standard
