11 Supplement
MINITRAC 31 • Profibus PA
43836-EN-131119
Profibus PA profile 3.02
Number of FBs with AI (function blocks
with analogue input)
3
Default values
Ʋ 1. FB PV
Ʋ 2. FB Electronics temperature
Ʋ 3. FB Pulse rate
Current value 10 mA, ±0.5 mA
Output variable - Density measurement
Output
Ʋ Output signal digital output signal, format according to IEEE-754
Ʋ Sensor address 126 (default setting)
Damping (63 % of the input variable) 0 … 999 s, adjustable
Profibus PA profile 3.02
Number of FBs with AI (function blocks
with analogue input)
3
Default values
Ʋ 1. FB PV
Ʋ 2. FB Electronics temperature
Ʋ 3. FB Pulse rate
Current value 10 mA, ±0.5 mA
Output variable - Level detection
Output
Ʋ Output signal digital output signal, format according to IEEE-754
Ʋ Sensor address 126 (default setting)
Damping (63 % of the input variable) 0 … 999 s, adjustable
Profibus PA profile 3.02
Number of FBs with AI (function blocks
with analogue input)
3
Default values
Ʋ 1. FB PV
Ʋ 2. FB Electronics temperature
Ʋ 3. FB Pulse rate
Current value 10 mA, ±0.5 mA
Output variable - X-ray alarm
Output
Ʋ Output signal digital output signal, format according to IEEE-754
Ʋ Sensor address 126 (default setting)
Damping (63 % of the input variable) 0 … 999 s, adjustable
