Product description
Protective measures
Protection IP 65
IP 68 (option for VEGADIF 35, 45 and 51)
Protection class III
CE conformity
VEGADIF 34, VEGADIF 35, VEGADIF 44, VEGADIF 45 and VEGADIF 51 differential pressure
transmitters meet the protective regulations of EMC (89/336/EWG) and NSR (73/23/EWG).
Conformity has been judged acc. to the following standards:
EMC
Emission EN 50 081 - 1
Susceptibility EN 50 082 - 2
NSR EN 61 010
Furthermore VEGADIF 35 is subject to the pressure instrument directive (97/23/EG):
- instruments with max. permissible pressures > 200 bar need the CE mark
- instruments with max. permissible pressures
≤
200 bar do not need the CE mark
NAMUR regulations
Full compliance with the NAMUR regulations NE21, May 1993.
Transmission reaction
Measuring ranges
VEGADIF 34 and VEGADIF 44
Features Limits Span System pressure Pressure transmission
Nom. liquid
meas. Initial Final value minimum maximum Overload Overload in the sensor
ranges value unilateral bilateral
25 mbar -25 mbar 25 mbar 5 mbar 25 mbar 10 bar 10 bar silicone oil 1)
100 mbar -100 mbar 100 mbar 5 mbar 100 mbar 16 bar 2) 25 bar 2) silicone oil 1)
500 mbar -500 mbar 500 mbar 25 mbar 500 mbar 100 bar 2) 140 bar 2) mineral oil 1)
3000 mbar -3000 mbar 3000 mbar 150 mbar 3000 mbar 100 bar 2) 140 bar 2) mineral oil 1)
VEGADIF 35, VEGADIF 45 and VEGADIF 51
Features Limits Span System pressure Pressure transmission
Nom. liquid
meas. Initial Final value minimum maximum Overload Overload in the sensor
ranges value unilateral bilateral
10 mbar 3) -10 mbar 10 mbar 2 mbar 10 mbar 140 bar 140 bar silicone oil 1)
40 mbar 3) -40 mbar 40 mbar 5 mbar 40 mbar 140 bar 140 bar silicone oil 1)
160 mbar -160 mbar 160 mbar 10 mbar 160 mbar 140 bar 140 bar silicone oil 1)
1000 mbar -1000 mbar 1000 mbar 50 mbar 1000 mbar 420 bar 4) 420 bar 4) silicone oil 1)
6000 mbar -6000 mbar 6000 mbar 300 mbar 6000 mbar 420 bar 4) 420 bar 4) silicone oil 1)
40000 mbar 3) -40000 mbar 40000 mbar 2000 mbar 40000 mbar 100 bar 420 bar 4) silicone oil 1)
1) In applications with pure gas Voltalef 1 A
2) 10 bar with process fitting PVDF for VEGADIF 34; 40 bar with process flange for VEGADIF 44
3) only VEGADIF 35
4) Note nominal pressure of the flanges
