8 VEGAMET 614V
Product description
Electrical protective measures
Instrument IP 30
Plug-in socket IP 20
Protection class II
Overvoltage category II
Electrical separating measures
Reliable separation acc. to
VDE 0106, part 1 between
power supply, fail safe and level relay
and meas. data inputs
- reference voltage 250 V
- insulation resistance 2.3 kV
Galvanic separation between relay outputs
- reference voltage 250 V
- insulation resistance 1.4 kV
Potential separation between DISBUS and outputs
- reference voltage 50 V
- insulation resistance 0.5 kV
Common reference potential at voltage and current output
Mechanical data
Series module unit with plug-in socket, incl. transpa-
rent cover, sensor terminal cover, coded
pin, two connection jumpers
Mounting carrier rail mounting acc. to DIN 46 277, Bl. 3
Dimensions, unmounted W = 72 mm, H = 118.5 mm, D = 134 mm
Weight approx. 480 g
CE conformity
The VEGAMET 614V Ex signal conditioning instrument meets the protective regulations of
EMC (89/336/EWG) and NSR (73/23/EWG). Only for use in industrial areas. Conformity has
been judged acc. to the following standards:
EMC
Emission EN 50 081 - 2: 1993
Susceptibility EN 50 082 - 2: 1995
NSR EN 61 010 - 1: 1993
