HW PROTOcOL INSTALLATION GUIDE
BACNET DESCRIPTIONS
All properties read-only unless otherwise noted. Preserved means it is non-volatile.
Present_Value Range Restrictions
Object Name Minimum Value Maximum Value
Device_Instance 0 (but see description, above) 4,194,302
Temp_Offset -5 5
RH_Offset -10 10
Standard Object Types Supported
Object Type Supported Optional
Properties
Writable Properties
Analog Input
-- AI
Description*, Reliability
Analog Value
-- AV
Description* Present_Value
Binary Value
– BV
Description* Present_Value
Device -- DEV Description*, Location APDU_Timeout, Description, Location,
Max_Master, Object_Identifier,
Object_Name
* Description is the same as the Object_Identifier. Reliability is “No Sensor” if no sensor is installed
(applies to humidity, temperature, and slider).
Objects Table
Object
Name
Type and
Instance
Description of Present_Value Property
Humidity AI 1 Humidity in percent
Temperature AI 2 Temperature in Fahrenheit or Celsius
Slider AI 3 Slider position in percent.
Device_
Instance
AV 1 Alternative way to change object_identifier property of
device. A negative value will restore the default device
instance (133nnn). Fractional values are truncated.
Temp_
Offset
AV 2 Temperature offset. Value rounded to nearest tenth of a
degree. Units are current units. Initial value is zero.
RH_Offset AV 3 Relative Humidity offset. Value rounded to the nearest tenth of
a percent. Initial value is zero.
Fahrenheit BV 1 1 if temperature in Fahrenheit, 0 if in Celsius. Initially 1
Override BV 2 1 if override button pressed. Store 0 to reset. Initially 0. Volatile
CONFORMANCE STATEMENT
Vendor Name: Veris Industries
Product Name: Veris HWxP Environmental Sensor
Product Model Number: HWxPxxx
Application Software Version: 1
Firmware Revision: x.x
BACnet Protocol Revision: 2
Product Description: Environmental Sensor
BACnet Standardized Device Profile (Annex L): BACnet Application Specific Controller
(B-ASC)
List all BACnet Interoperability Building Blocks Supported (Annex K):
DS-RP-B,DS-RPM-B,DS_WP-B,DM-DDB-B,DM-DOB-B,,DM-DCC-B
Segmentation Capability: Segmentation not supported
Standard Object Types Supported:
No dynamic creation or deletion supported
No proprietary properties or object types
(other information about objects on preceding pages)
Data Link Layer Options: MS/TP master (Clause 9), baud rates: 9600, 19200, 38400,
76800
Device Address Binding: Static device binding is not supported. (No client functional-
ity is included).
Networking Options: None
Character Sets Supported: ANSI X3.4
Device Objects Table
Object
Name
Type and
Instance
Object
Property
Description
HWxPxxx Device
133nnn
Object_Identifier
(R/W)
Unique value where nnn initially is MS/TP
Object_Name
(R/W)
Unique name, initially a combination of
model and serial number. Maximum length
is 64 characters
APDU_Timeout Default is 3000, maximum value is 60000
Max_Master Default is 127
Description Maximum length is 64 characters
Location Maximum length is 64 characters
