Monitoring at Mains
E3xA
E3xB
E3xC
Current per phase
n
n
n
Max. current per phase
n
n
n
Current demand per phase
n
n
n
Max. current demand per phase
n
n
n
Energy (kWh) per phase
n
n
Real Power (kW) per phase
n
n
Apparent Power (kVA)
n
n
Power factor total *
n
n
Power factor per phase
n
n
Voltage, L-L and average
n
n
Voltage, L-N and average
n
n
Voltage, L-N and per phase
n
n
Frequency (phase A)
n
n
Monitoring at Branch Circuit
Current
n
n
n
Max. current
n
n
n
Current demand
n
n
n
Max. current demand
n
n
n
Real power (kW)
n
Real power (kW) demand
n
Real power (kW) demand max.
n
Energy (kWh) per circuit
n
Power factor
n
Apparent Power (kVA)
n
Modbus Alarms
Voltage over/under
n
n
Current over/under
n
n
n
* Based on a 3-phase breaker rotation.
DATA OUTPUT
7.3”
(184 mm)
8.9”
(226 mm)
5.8”
(146 mm)
4.8”
(122 mm)
3.9”
(100 mm)
7.9”
(200 mm)
8.3”
(211 mm)
1.75”
(45 mm)
Ø = 0.2”
(5 mm)
DIMENSIONAL DRAWINGS
Height
(Board + Bracket)
1.7” (44 mm)
0A
Ch. 2
Ch. 1
TIME
High High
High Alarm
Latched
Low Alarm
Latched
No Alarm
Latched
Low Low Alarm Latched
High
Low Low
Low
AMPS
OPERATION EXAMPLE
ACCESSORIES
Ribbon Cables, round or flat (CBLxxx)
E3x cover (AE001)
Modbus TCP Gateway (U013-0012)
Modbus-to-BACnet Converter (E8950)
Network Display (H8932, H8936)
CTs (E31CT0, E31CT1, E31CT3)
CTs for auxiliary inputs (H681x)
Repair kit for E30 (AE006)
AE001
U013-0012
AE006
CBL022
H681x
H8932/H8936
E31CT0
E31CT1
E31CT3
E8950
