Hot Tap
For pipes that cannot be drained even for initial installation, we offer a Hot Tap version
Model THT – available in the 10k Ω Thermistor version only
Figure 6: Hot Tap
Electrical Installation
All connections to the 340 BN/MB Btu Energy Transmitter are made to screw terminals on removable headers
Figure 7: Side View - Typical Series 300 Removable Connector Wiring
3/32" Flathead
Screwdriver
Series 300
Connector
Wire
Data Industrial® 340 BN/MB BTU Energy Transmitter
Page 8
July 2012
