H8186-CB INSTALLATIoN GUIDe
bacnet Protocol
BACnet Protocol Implementation Conformance Statement
Date: August 2, 2007
Vendor Name: Veris Industries
Product Name: BACnet Communications Board for
H81xx Energy Meter
Product Model Number: H8186-CB
Applications Software Version: 1
Firmware Revision:
1.09
BACnet Protocol Revision: 2
Product Description: Provides BACnet MS/TP connectivity to
the Veris H81xx Energy Meter
BACnet Standardized Device Profile (Annex L):
BACnet Application Specific Controller (B-ASC)
List all BACnet Interoperability Building Blocks Supported (Annex K):
DS-RP-B, DS-RPM-B, DS-WP-B, DM-DDB-B, DM-DOB-B, DM-DCC-B
Segmentation Capability:
Segmentation not supported
Standard Object Types Supported:
No dynamic Creation or Deletion supported
No proprietary properties or object types
Device Object:
Optional Properties Supported:
Max_Master, Max_Info_Frames, Description, Location
Writable Properties:
Object_Identifier, Max_Master, Location
Property Range Restrictions:
Location (limited to 64 characters)
Analog Input Object:
Optional Properties Supported:
Description
No Writable Properties.
Analog Value Object:
Optional Properties Supported:
Description
Writable Properties:
Only the Present_Value is writable.
Property Range Restrictions:
1) Only the value 0.0 may be written to the Present_Value
of AV1. This action will clear the kWh-Accumulator in the
H81xx Energy Meter.
2) Although a REAL (i.e. floating point) value, writing the
Present_Value of AV2 is an alternative method of changing
the Device_Instance. This value may be written in the range
0-4194302. Any fractional value will be truncated (eg. 57.234
will be written as 57).
Data Link Layer Options:
MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400
Device Address Binding:
Static device binding is not supported. (No client functionality is included).
Networking Options:
None
Character Sets Supported:
ANSI X3.4
