INSTALLATION INSTRUCTIONS
M S D
• W W W . M S D P E R F O R M A N C E . C O M • ( 9 1 5 ) 8 5 5 - 7 1 2 3 • F A X ( 9 1 5 ) 8 5 7 - 3 3 4 4
ALT
A. Not Used
B. Brown - L Term
C. Not Used
D. Not Used
1. Orange - 5V
2. Black - Groun
d
3. Blue - Signal
TPS ADAPTER
TP
S
Si
gnal
-
Bl
ue
ALT
1. Brown-L Term
2. Not Used
MAP
ECT
INJ8*
INJ6*
COIL
S
1, 3, 5,
7
CAN
CAN
ETC
/
V V T
COIL
S
2, 4, 6,
8
DRIVER
SIDE
PASSENGER
SIDE
INJ4*
INJ2*
INJ7*
INJ5*
IAC
ETC/TPS
INJ1*
INJ3*
OIL
CRAN
K
Red - POWER
Red - POWER
IAT
Orange - AC
IAC2
FPS
F
G
H
E
F
G
D LPHI
D LPHI
Black - GROUND
Blac
k
GROUND
CAM
Red - POWER
TO
POWER
MODULE
*INJECTORS ADAPTERS
ARE INTERCHANGEABLE.
(EV6 Adapters shown)
NOTE: Do not cross the
injector harnesses when
installing them on the
injectors.
A. Pink - 12V
B. Orange - 5
V
C. Brown - Ground
D. Org/Yel - Signal
1. Signal
2. 12V
1. Signal
2. 12V
A. Black - Groun
d
B. Tan - Coil
2
C. Lt. Green - Coil
4
D. Not Used
E. Brown - Ref Gnd
F. White - Coil
6
G. Lt. Blue - Coil
8
H. Pink - 12V
A. Orange - 5V
B. Lt Green - Signa
l
C. Brown - Ground
1. Signal
2. 12V
1. Signal
2. 12V
A. Black - Groun
d
B. Violet - Signal
A. Black - Ground
B. Yellow - Signal
A. Orange - Coil 1B
B. Gray - Coil 1A
C. Blue - Coil 2A
D. Black - Coil 2B
A. Orange - Coil 1B
B. Gray - Coil 1A
C. Blue - Coil 2A
D. Black - Coil 2B
A. Brow
n
B. Pink
C. Brn/White - Gnd
D. Not Used
E. Green - TPS1
F. Orange - 5V
G. Violet - TPS2
H. Not Used
A. Brow
n
B. Pink
C. Brn/White - Gnd
D. Not Used
E. Green - TPS1
F. Orange - 5V
G. Violet - TPS2
H. Not Used
1. Green - CAN LO
2. Yellow - CAN HI
3. Blk/Red - Gnd
4. Black - Gnd
5. Orange - Crank
6. Brown - Cam
7. Blue - Tsync
8. Gray - Shiel
d
1. Black - Groun
d
2. Orange - 5V
3. White - Signa
l
1. Signal
2. 12V
1. Black - Groun
d
2. Orange - 5V
3. Lt Blue - Signa
l
A. Black - Groun
d
B. Blue - Coil
7
C. Brn/White - Coil
5
D. Not Used
E. Brown - Ref Groun
d
F. Green - Coil
3
G. Tan - Coil
1
H. Pink - 12V
A. Pink - 12V
B. Orange - 5V
C. Brown - Ground
D. Brn/Wht - Signal
1. Signal
2. 12V
1. Signal
2. 12V
1. Signal
2. 12V
(NOT
CURRENTLY
USED)
ALTERNATOR NOTE:
Both types of alterna
-
tor connectors have
been provided to
accommodate the
different configurations.
Cut the one not used
and cap the wire with
the heatshrink provided
in the parts bag.
Figure 19 Wiring
