IP Director Version 4.3 – User Manual – Part 2: Logging and Browsing
EVS Broadcast Equipment
Issue 4.3.C
7
D
EFINING A
P
REVIEW
R
ECORDER
The preview recorder definition is used to provide the timecode
displayed in the LIVE area of the log sheet. It will also be the
angle selected when the operator double-clicks on an event in a
log that loads to an associated channel for viewing.
To define a preview recorder, right-click the requested recorder
in the Log Relevant Recorders Selection field and select
Preview Recorder from the contextual menu.
Note
The preview recorder MUST be assigned to a record
channel that is managed with a RS422 link to the XT
server the channel is on. If not, the log sheet will NOT
function correctly, and no LIVE timecode will be
displayed.
1.2.4 S
TEP
4: D
EFINING THE
U
SER
’
S
F
IELDS
This step allows the users to define all the user’s fields that are
requested in the selected logging profile. If no logging profile
has been defined in step 1 or if no user field section has been
defined in the logging profile, this area will remain dimmed and
inaccessible.
If a logging profile has been selected, then more information can
be added to the log using the user’s field definitions available in
the wizard.
The information specified in the User’s Field Definition window
will be found in the log entries as additional columns.
