IP Director Version 4.3 – User Manual – Part 2: Logging and Browsing

EVS Broadcast Equipment

Issue 4.3.C

3

G

ENERAL

L

OG

S

HEET

I

NFORMATION

Option Description

Name

Name of the log sheet. This is a
mandatory field.

Parent

Name of the folder in which the log
sheet is to be filed in the tree
structure of the Database Explorer.
Browsing in this field displays the
folders already created in the Logs
section of the Database Explorer,
allowing the users to select the
requested folder.

Date

Date when the log sheet is created
or date of the logged event. This is a

mandatory field.

Description

Description that will only appear in

this window. This is optional.

Automatically

Export Logs to 3

r d

Party

Check box to be selected to

generate an .xml file of the log sheet
each time it is modified (new log
element, relevant recorders
modified, etc.). The IP Scheduler
service will create the .xml file and

send it to a dedicated folder.

The option availability depends on
the configuration defined in the
Configure > Log Export menu of the
Remote Installer. More precisely, it

depends on the Automatically
Export All New Logs
option and the
definition of a dedicated folder for
export. See Technical Reference
manual for more information.

L

OGGING

P

ROFILE

I

NFORMATION

A logging profile is a file generated to enable specific user fields
to be added to a log sheet or “automatic keywords” to be
managed in log elements on a log sheet.

Initially, the logging profiles must be created outside the IP

Director interface as an .xml file. In a later release they will be
created from within IP Director. See section 1.4.5 “How to Import
a Logging Profile”
, on page 14 for details on the import.

A list of all imported logging profiles will be shown in the Name
drop-down list:
