Issue 4.3.C

IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing

EVS Broadcast Equipment

88

Icon Description

When this yellow icon is selected, the clips
which are still in the process of being sent to
AVID fulfil the Status criterion.

When this green icon is selected, the clips
which have successfully been sent to a

destination target fulfil the Status criterion.

When this icon is selected, the clips which

have successfully been sent to an XFile fulfil
the Status criterion.

When this green icon is selected, the clips
which have successfully been sent to an
XStore platform (running a CleanEdit
application) fulfil the Status criterion.

When this green icon is selected, the clips
which have successfully been sent to AVID
fulfil the Status criterion.

When this red icon is selected, the clips for
which the transfer to an XFile ended with

errors fulfil the Status criterion.

When this red icon is selected, the clips for
which the transfer to an XStore platform
(running a CleanEdit application) ended with
errors fulfil the Status criterion.

When this red icon is selected, the clips for
which the transfer to AVID ended with errors
fulfil the Status criterion.

T

YPE

The Type criterion allows specifying a clip type or no clip type.
The clips to which the selected type has been assigned will meet
the Type criterion.

The table below describes the possible types that can be taken
into account in the bin rule:

Icon Description

When this icon is selected, the clips which
have no specific type assigned fulfil the Type
criterion.
