Installation, Administration and Maintenance
Aastra depl-0900/0.4 Page: 64 (104)
select the antenna with the best transmission and reception characteristics.
The WLAN section is only available for RFP L42 WLAN.
IMPORTANT: A RFP which is configured as OMM cannot simultaneously
operate as a WLAN Access Point.
3.3.5.3 Requirements for the WLAN
WLAN adapters that conform to the 802.11b or the 802.11g standard are a
prerequisite for operating WLAN clients. As far as WEP and WPA encryption
and the utilisation of a Radius infrastructure are concerned, it must be
ensured the WLAN network adapters running under the client operating
system support the required modes. However, it is always necessary to
check the operability of the adapters before putting them into service.
3.3.6 System features
3.3.6.1 Central configuration of LDAP access
The following parameters are set by OMM Web service. The configuration is
valid for all PP handsets, LDAP call by name is enabled for. The OMM
supports LDAP simple bind.
Field description :
•
Server Name and Server Port (mandatory)
- Server Name or Server IP Address
- Server Port (default: 389)
Please note: SSL (default port 689) is not supported
•
Root Directory
The search base has to be edited (e.g. “ou=people,o=my com”).
•
User Name and User Password
User name (a distinguished name) and password may be filled, if
requested by the LDAP Server. Otherwise an anonymous bind takes
place.
Please note: the DECT IP OMM supports LDAP simple bind
•
Search Attribute
Searches will be done for one of the following attributes
