12. Place the jack under the jacking

point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
resting in the jack notch.

13. Use the extension and the wheel

nut wrench as shown to raise the
vehicle until the flat tire is off the
ground.

14. Remove the wheel nuts, then

remove the flat tire.

15. Before mounting the spare tire,

wipe any dirt off the mounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully; it may be hot from
driving.

JACKING POINT

EXTENSION

WHEEL NUT WRENCH

BRAKE HUB

Changing a Flat Tire

548
