(Passenger's side)
Use a flat-tip screwdriver to
remove the holding clip from the
engine coolant reserve tank, and
then remove the engine coolant
reserve tank.
Remove the cap from the engine
coolant reserve tank (use towel to
wipe fluid).
Unclip hose from the stay brackets
on the engine coolant reserve
tank.
3. Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
4. Remove the bulb by turning it
about one-quarter turn
counterclockwise.
5. Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
6. Push the electrical connector onto
the new bulb.
7. Turn on the headlights to test the
new bulb.
8. (Passenger's side)
Install the engine coolant reserve
tank and power steering reserve
tank.
HOLDING CLIP
CAP
ENGINE COOLANT
RESERVOIR
BULB
CONNECTOR
Lights
522
