Lights, 2011 mdx – Acura 2011 MDX User Manual

Page 530

background image

4. Remove the socket by turning it

one-quarter turn counterclockwise.

5. Pull the bulb straight out of its

socket.

6. Push the new bulb straight into

the socket until it bottoms.

7. Turn on the lights to make sure

the new bulb is working.

8. Put the socket back into the light

assembly, and turn it clockwise to
lock it in place.

9. Install the rear light assembly in

the rear pillar. Tighten the two
bolts. Snap the bolt covers into
position.

Replacing a Back-up Light Bulb

1. Open the tailgate. Place a cloth on

the edge of the light assembly
cover. Remove the cover by
carefully prying in the notch on its
middle edge with a flat-tip
screwdriver.

BULB

SOCKET

COVER

Lights

526

10/06/29 11:59:04 11 ACURA MDX MMC North America Owner's M 50 31STX640 enu

2011 MDX
