6.7.2 INSTALL THE NEW SYSTEM COOLING FANS
To install the new system cooling fans, please follow the steps below.

Step 1: Insert the system cooling fans into the chassis and attach to the left panel with the previ-

ously removed retention screws.

Step 2: Rebundle the new fan wires and tie them to the chassis like the old fan wires.

Step 3: Reconnect the new fan connector to the motherboard.

Step 4: Reattach the elevated platform.

Step 5: Replace the back cover.
