14628 Central Blvd,

Chino, CA91710

tel:909.597.7588, fax:909.597.1939

© Copyright 2011 Acnodes, Inc.

All rights reserved. Product description and product specifications

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

PC 6408

8” Fanless Panel PC

4.10 Activating the Front USB Connectors

A USB switch on the I/O panel of the PC5153/ PC5173 activates the two USB connec-

tors on the front panel. To access the USB connectors and activate the connectors,

please do the following:

Step 1: Open the cover. The USB connectors are secured to the front panel of the

PC5153/ PC5173 with two retention screws. Remove these screws.

Step 2: Activate the USB connectors. To activate the USB connectors, move the USB

switch to the left.
