Step 2. Mounting the RAID System and Installing Hard Disk
Mounting the RAID system
The RAID system/Rail Extenders can be installed in a standard 19-inch
rack. Follow the procedures below:
1. Attack eight rack nuts into the rack,
making sure that they correspond with
the mounting points on the rails.
2. Adjust the length of the rails as
needed.
3. Secure the rails using two nuts and
bolts on both the front and back posts
of the rack then tighten the locking
screws.
4. When necessary, install the rail
extenders by attaching the screws to
secure them.
5. Slide the RAID system into the rack
and secure it into place using the
fixing screws.
