Accusys A16R/A16U-IS
12
Step 5. Disk Array and iSCSI Port Configuration
I. Build a DAS with Clustering Environment
This page will show steps to build an DAS with clustering server environment. Array
volume will be presented as a block-based storage device (like SCSI disk) to two
clustering server nodes by through traditional Ethernet. Follow the steps below to
configure RAID.
Task List
A. Pre-Setting
B. Create Disk Groups
C. Create Logical Disks
D1. Set iSCSI Port
E. Set iSCSI Target
F. LUN Mapping
G. Set iSCSI Initiator on Windows
Fan 1 Fan 3
Contraller A
Fan 2
Contraller B
P/S 1 P/S 2
VER 1.0
P/S
UPS
Chassis
ID
5 6 78 9 0
COM LAN
EXP EXP Access
EXP Link CTRL Ready
CH 2 CH 1
Preferred Ctrl: A
Controller A
Clustering Server 1 Clustering Server 0
ispa4 ispa2 ispa1 ispa3
DG0LD0
Ist1: 192.168.2.12 Ist0: 192.168.2.10
hear-beat
