Types of Possible Input Signals
Video
Analog Video Signal 480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz
Digital Video Signal 480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz,
1080p/24 Hz, 1080p/50 Hz, 1080p/60 Hz
3D Signal Frame Packing 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz, 1080i/50 Hz, 1080i/60 Hz
Side-by-side 1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz, 1080p/50 Hz, 1080p/24 Hz,
720p/50 Hz, 720p/60 Hz
Top-and-bottom 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz
PC signal (HDMI)
No. Designation Resolution fh [kHz] fv [Hz]
dot CLK
[MHz]
Total No.
of Dots
[dot]
Total No.
of Lines
[line]
No. of
Effective
Dots [dot]
No. of
Effective
Lines
[line]
1 VGA 60 640×480 31,500 60,000 25,200 800 525 640 480
2 VGA 59.94 640×480 31,469 59,940 25,175 800 525 640 480
3 SVGA 60 800×600 37,879 60,317 40,000 1.056 628 800 600
4 XGA 60 1024×768 48,363 60,004 65,000 1.344 806 1.024 768
5 WXGA 60 1280×768 47,760 60,000 79,998 1.675 796 1.280 768
6 WXGA+ 60 1440×900 55,919 59,999 106,470 1.904 932 1.440 900
7 SXGA 60 1280×1024 63,981 60,020 108,000 1.688 1.066 1.280 1.024
8 WSXGA+ 60 1680×1050 65,222 60,002 147,140 2.256 1.087 1.680 1.050
9 WUXGA 60 1920×1200 74,038 59.95 154,000 2.080 1.235 1.920 1.200
79
Others
