17
5.3 Emission levels
Levels determined in accordance with EN 61029
are typically:
Sound pressure level
88 dB(A)
Noise level 101 dB(A)
Measuring uncertainty allowance K = 3 dB
Wear ear protection.
Measured acceleration < 2.5 m/s²
The specifi ed emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary
estimates regarding vibration and noise loads
during operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with
other insertion tools or if not maintained adequat-
ely. Take note of idling and downtimes of machine!
6 Commissioning
Warning
• Observe the mains voltage: The voltage and
frequency of the power source must comply with
the specifi cations on the machine's identifi ca-
tion plate.
• In North America, only Festool machines with
the voltage specifi cations 120 V/60 Hz may be
used.
Prior to initial operation:
– Remove the transport safety device (4.4) from
the guide rod.
On/Off switch
– Press the on/off switch (1.2) as far as possible
to unlock the saw unit and the pivot guard.
– Press the switch-on lock (1.3).
– Press the on/off switch (1.2) all the way in to
start the machine.
– Release the on/off switch again to switch off the
machine.
7 Adjustments
Always pull the plug out of the socket
before performing any type of work on
the machine.
KS 120 EB only: Replace the laser warning sticker
(3.1) with the relevant accompanying warning
sticker in your language.
7.1 Transport
Securing the machine (transport position)
– Press the on/off switch (4.1).
– Swivel the saw unit downwards until it reaches
the fence.
– Press the lock (4.2). The saw unit now remains
in the lower position.
– Tighten the rotary knob (4.3) to secure the saw
unit in the rear position.
– Wind up the mains cable into the cable holder
(5.5) before transporting.
– Stow away the Allen key (5.4) and the bevel (5.3)
(KS 120 EB only) in the holders provided.
Never carry or lift the machine by the
movable pivot guard (5.1).
Carry the machine by the edge of the saw table
(5.2) and the handle (5.5) in the cable holder.
Unlocking the machine (working position)
– Push the saw unit down slightly and remove the
transport safety device (4.2).
– Swivel the saw unit upwards.
– Unscrew the rotary knob (4.3).
7.2 Mounting the machine
Always pull the plug out of the socket
before performing any type of work on
the machine.
Before using the machine, set up on a level, stable
work surface (e.g. the underframe UG-KAPEX, the
multifunction table MFT or a worktop).
The following assembly options are available:
Fastening: Secure the machine on the work sur-
face using four screws. Use the holes (6.1) on the
four support points on the saw table.
Clamps: Secure the machine on the work surface
using four clamps. The fl at surfaces (6.2) on the
four saw table support points are used as clamp-
ing surfaces.
Clamping set (for MFT): Secure the machine on
the Festool multifunction table MFT using the
clamping set (6.4, 494693). Use the two screw
holes (6.3).
Underframe UG-KAPEX
Secure the machine on the underframe as de-
scribed in the assembly instructions enclosed
with the underframe.
7.3 Changing tools
Risk of accidents
• Always pull the mains plug out of the socket
before changing blades.
• Actuate the spindle lock (7.2) only after the saw
