Dimension ES-3124PWR Ethernet Switch
IEEE 802.1Q Tagged VLAN Commands 31-5
frame-type
where
= Specifies all Ethernet frames (tagged and untagged) or only tagged Ethernet
frames.
This command sets the specified port to accept all Ethernet frames or only those with an IEEE 802.1Q VLAN tag.
The following example sets ports 1 to 5 to accept only tagged frames.
Figure 31-6 frame type Command Example
31.5.3 Enable or Disable Port GVRP
Use the gvrp command to enable GVRP on the port(s). Use the no gvrp command to disable GVRP.
The following example turns off GVRP for ports 1 to 5.
Figure 31-7 no gvrp Command Example
31.5.4 Modify Static VLAN
Use the following commands in the config-vlan mode to configure the static VLAN table.
Syntax:
vlan
fixed
forbidden
name
normal
untagged
no fixed
no forbidden
no untagged
where
= The VLAN ID [1 – 4094].
= A name to identify the SVLAN entry.
= This is the switch port list.
ras(config)# interface 1-5
ras(config-interface)# frame-type tagged
ras(config)# interface 1-5
ras(config-interface)# no gvrp
