Dimension ES-3124PWR Ethernet Switch
31-4 IEEE 802.1Q Tagged VLAN Commands
Figure 31-4 garp status Command Example
31.4.4 Enable GVRP
Syntax:
vlan1q gvrp
This command turns on GVRP in order to propagate VLAN information beyond the switch.
31.4.5 Disable GVRP
Syntax:
no vlan1q gvrp
This command turns off GVRP so that the switch does not propagate VLAN information to other switches.
31.5 Port VLAN Commands
You must configure the switch port VLAN settings in config-interface mode.
31.5.1 Set Port VID
Syntax:
pvid
where
= Specifies the VLAN number between 1 and 4094
This command sets the default VLAN ID on the port(s).
The following example sets the default VID to 200 on ports 1 to 5.
Figure 31-5 vlan1q port default vid Command Example
31.5.2 Set Acceptable Frame Type
Syntax:
ras# show vlan1q gvrp
GVRP Support
---------------------
gvrpEnable = YES
ras(config)# interface 1-5
ras(config-interface)# pvid 200
