Chapter 1 Getting to Know Your NBG-318S
NBG-318S User’s Guide
32
WAN
Green
On
The NBG-318S has a successful 10Mb WAN
connection.
Blinking
The NBG-318S is sending/receiving data.
Amber
On
The NBG-318S has a successful 100Mb Ethernet
connection.
Blinking
The NBG-318S is sending/receiving data.
None
Off
The WAN connection is not ready, or has failed.
LAN 1-3
Green
On
The NBG-318S has a successful 10Mb Ethernet
connection.
Blinking
The NBG-318S is sending/receiving data.
Amber
On
The NBG-318S has a successful 100Mb Ethernet
connection.
Blinking
The NBG-318S is sending/receiving data.
Off
The LAN is not connected.
WLAN
Green
On
The NBG-318S is ready, but is not sending/receiving
data through the wireless LAN.
Blinking
The NBG-318S is sending/receiving data through the
wireless LAN.
None
Off
The wireless LAN is not ready or has failed.
WPS
WPS (WiFi Protected Setup) automatically sets up security on your wireless
network. This function is currently unavailable
Table 1 Front Panel LEDs (continued)
LED
ICON
COLOR
STATUS
DESCRIPTION
