NBG-318S User’s Guide
105
C
H A P T E R
8
HomePlug AV
This chapter introduces the main applications and management of the powerline feature.
8.1 Overview
The NBG-318S is a HomePlug AV compliant powerline Ethernet adapter. The NBG-318S and
other HomePlug AV powerline adapters in your network communicate with each other by
sending and receiving information over your home’s electrical wiring.
The NBG-318S plugs into an ordinary outlet to create a new network which can extend to any
other electrical outlet in any room of a house.
The following section shows you a typical application.
Figure 55 Expand Your Network
To set up your powerline network do the following.
1 Connect your NBG-318S to the Internet.
2 Then plug your NBG-318S into a power outlet.
The NBG-318S is ready for connection on a powerline network.
3 Connect another HomePlug AV compatible adapter to a computer and then plug it in on
the same home or office wiring.
