ZyXEL Communications NBG-318S - Manual (Page 103)

Chapter 7 LAN
NBG-318S User’s Guide
103
Figure 53 Network > LAN > IP Alias
The following table describes the labels in this screen.
Table 38 Network > LAN > IP Alias
LABEL DESCRIPTION
IP Alias 1,2 Select the check box to configure another LAN network for the NBG-318S.
IP Address Enter the IP address of your NBG-318S in dotted decimal notation.
IP Subnet Mask Your NBG-318S will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the
subnet mask computed by the NBG-318S.
Apply Click Apply to save your changes back to the NBG-318S.
Reset Click Reset to begin configuring this screen afresh.
7.5 Advanced LAN Screen
To change your NBG-318S’s advanced IP settings, click Network > LAN > Advanced. The
screen appears as shown.
Figure 54 Network > LAN > Advanced
