TABLE 6: COOLING CAPACITIES - 4 TON (DEB048)
TEMPERATURE
OF AIR ON
OUTDOOR COIL
AIR ON INDOOR COIL
1200 CFM 1400 CFM 1600 CFM 1800 CFM 2000 CFM
WB °F WB °F WB °F WB °F WB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
49.2 46.1 41.6 41.3 50.6 47.4 42.9 42.5 52.1 48.8 44.1 43.7 52.8 49.4 44.7 44.2 53.4 50.1 45.2 44.8
Total Power
Input kW
4.47 4.44 4.35 4.33 4.59 4.57 4.47 4.45 4.72 4.69 4.59 4.57 4.78 4.76 4.66 4.63 4.85 4.83 4.72 4.70
Sen
s
ib
le Capacit
y
MBH
1
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity
En
te
ri
n
g
D
ry
Bu
lb
°
F
86 28.3 35.7 41.3 41.3 31.5 39.6 42.7 42.5 34.7 43.5 44.1 43.7 37.1 46.3 44.7 44.2 39.5 49.1 45.2 44.8
83 24.9 32.3 37.8 39.5 27.4 35.6 41.0 41.6 30.0 38.9 44.1 43.7 31.8 41.0 44.7 44.2 33.5 43.2 45.2 44.8
80 21.4 28.9 34.4 36.1 23.4 31.6 37.6 39.4 25.4 34.2 40.7 42.7 26.5 35.7 42.5 43.8 27.6 37.2 44.3 44.8
77 18.0 25.5 31.0 32.7 19.4 27.5 33.5 35.4 20.7 29.5 36.1 38.1 21.2 30.4 37.2 38.5 21.6 31.2 38.3 38.9
74 14.6 22.1 27.6 29.3 15.3 23.5 29.5 31.3 16.0 24.9 31.4 33.4 15.8 25.1 31.9 33.1 15.7 25.3 32.4 32.9
71 - 18.6 24.2 25.8 - 19.4 25.4 27.3 - 20.2 26.7 28.7 - 19.8 26.6 27.8 - 19.3 26.4 26.9
68 - 15.2 20.7 22.4 - 15.4 21.4 23.2 - 15.5 22.1 24.1 - 14.4 21.3 22.5 - 13.4 20.4 21.0
95 °F
Net Cap
MBH
47.2 43.4 39.3 38.8 48.6 44.7 40.5 40.0 50.0 46.0 41.7 41.1 48.9 45.0 40.8 40.2 47.8 44.0 39.9 39.3
Total Power
Input kW
4.88 4.85 4.74 4.74 5.00 4.97 4.86 4.86 5.13 5.09 4.98 4.98 5.23 5.20 5.09 5.08 5.34 5.31 5.19 5.19
Sensib
le C
a
pacit
y
MBH
1
E
n
te
ring Dry
Bu
lb °F
86 27.7 34.7 39.3 38.8 30.6 38.3 40.5 40.0 33.6 41.9 41.7 41.1 35.3 42.9 40.8 40.2 37.0 44.0 39.9 39.3.
83 24.2 31.3 36.5 37.9 26.6 34.2 39.1 39.5 28.9 37.2 41.7 41.1 30.0 38.3 40.8 40.2 31.0 39.5 39.9 39.3
80 20.8 27.9 33.0 34.5 22.5 30.2 35.8 37.4 24.3 32.5 38.5 40.2 24.7 33.0 39.1 39.8 25.0 33.5 39.7 39.3
77 17.4 24.5 29.6 31.1 18.5 26.2 31.7 33.3 19.6 27.9 33.9 35.6 19.3 27.7 33.8 34.5 19.1 27.6 33.8 33.3
74 14.0 21.0 26.2 27.7 14.5 22.1 27.7 29.3 14.9 23.2 29.2 30.9 14.0 22.4 28.5 29.1 13.1 21.6 27.8 27.4
71 - 17.6 22.8 24.2 - 18.1 23.7 25.2 - 18.5 24.5 26.2 - 17.1 23.2 23.8 - 15.7 21.9 21.4
68 - 14.2 19.4 20.8 - 14.0 19.6 21.2 - 13.9 19.9 21.6 - 11.8 17.9 18.5 - 9.7 15.9 15.5
105 °F
Net Cap
MBH
45.5 40.1 37.8 37.4 46.1 40.6 38.3 37.9 46.7 41.1 38.8 38.3 46.3 40.8 38.5 38.0 46.0 40.4 38.2 37.7
Total Power
Input kW
5.37 5.30 5.21 5.21 5.49 5.43 5.34 5.33 5.62 5.55 5.46 5.45 5.72 5.66 5.56 5.55 5.83 5.76 5.66 5.65
S
ensible
Cap
a
city
MBH
1
Ent
e
ri
ng Dry
Bul
b
°
F
86 27.0 33.2 37.8 37.4 29.6 36.1 38.3 37.9 32.3 39.1 38.8 38.3 34.3 39.7 38.5 38.0 36.4 40.4 38.2 37.7
83 23.6 29.8 35.7 36.3 25.6 32.2 37.3 37.3 37.6 34.7 38.8 38.3 29.0 36.3 38.5 38.0 30.4 38.0 38.2 37.7
80 20.1 26.4 32.3 32.9 21.5 28.2 34.6 35.2 22.9 30.0 36.8 37.5 23.7 31.0 37.5 37.6 24.5 32.0 38.1 37.7
77 16.7 22.9 28.9 29.5 17.5 24.2 30.5 31.2 18.3 25.4 32.1 32.8 18.4 25.7 32.1 32.3 18.5 26.0 32.1 31.8
74 13.3 19.5 25.5 26.1 13.5 20.1 26.5 27.1 13.6 20.7 27.5 28.2 13.1 20.4 26.8 27.0 12.5 20.1 26.2 25.8
71 - 16.1 22.0 22.7 - 16.1 22.4 23.1 - 16.0 22.8 23.5 - 15.1 21.5 21.7 - 14.1 20.2 19.8
68 - 12.7 18.6 19.2 - 12.0 18.4 19.0 - 11.6 18.1 18.8 - 9.8 16.2 16.4 - 8.1 14.3 13.9
115 °F
Net Cap
MBH
43.9 36.7 36.3 36.0 43.6 36.5 36.1 35.8 43.3 36.3 35.8 35.5 43.7 36.6 36.2 35.8 44.1 36.9 36.5 36.2
Total Power
Input kW
5.86 5.76 5.69 5.67 5.98 5.88 5.81 5.80 6.11 6.01 5.94 5.92 6.22 6.11 6.04 6.02 6.32 6.21 6.14 6.12
Se
nsible Capa
c
ity
MB
H
1
E
n
te
ri
ng
D
ry
Bulb
°
F
86 26.3 31.7 36.3 36.0 28.6 34.0 36.1 35.8 30.9 36.3 35.8 35.5 33.4 36.6 36.2 35.8 35.8 36.9 36.5 36.2
83 22.9 28.3 35.0 34.8 24.6 30.2 35.4 35.1 26.3 32.2 35.8 35.5 28.1 34.3 36.2 35.8 29.8 36.4 36.5 36.2
80 19.5 24.8 31.6 31.3 20.5 26.2 33.3 33.1 21.6 27.6 35.1 34.8 22.7 29.0 35.8 35.5 23.9 30.5 36.5 36.2
77 16.1 21.4 28.2 27.9 16.5 22.2 29.3 29.0 17.0 22.9 30.4 30.1 17.4 23.7 30.4 30.2 17.9 24.5 30.5 30.2
74 12.6 18.0 24.7 24.5 12.5 18.1 25.2 25.0 12.3 18.2 25.7 25.4 12.1 18.4 25.1 24.8 12.0 18.5 24.5 24.2
71 - 14.6 21.3 21.1 - 14.1 21.2 20.9 - 13.6 21.1 20.8 - 13.1 19.8 19.5 - 12.6 18.6 18.3
68 - 11.1 17.9 17.6 - 10.0 17.1 16.9 - 8.9 16.4 16.1 - 7.8 14.5 14.2 - 6.6 12.6 12.3
125 °F
Net Cap
MBH
42.2 33.4 34.8 34.6 41.1 32.4 33.8 33.7 40.0 31.4 32.9 32.7 41.1 32.4 33.8 33.7 42.2 33.4 34.8 34.6
Total Power
Input kW
6.3 6.2 6.2 6.1 6.5 6.3 6.3 6.3 6.6 6.5 6.4 6.4 6.7 6.6 6.5 6.5 6.8 6.7 6.6 6.6
Sen
s
ib
le Capacit
y
MBH
1
En
te
ri
n
g
D
ry
Bu
lb
°
F
86 25.6 30.1 34.8 34.6 27.6 31.8 33.8 33.7 29.6 31.4 32.9 32.7 32.4 32.4 33.8 33.7 35.2 33.4 34.8 34.6
83 22.2 26.7 34.3 33.2 23.6 28.2 33.6 32.9 25.0 29.8 32.9 32.7 27.1 32.3 33.8 33.7 29.3 33.4 34.8 34.6
80 18.8 23.3 30.8 29.8 19.5 24.2 32.1 30.9 20.3 25.1 32.9 32.1 21.8 27.0 33.8 33.3 23.3 28.9 34.8 34.6
77 15.4 19.9 27.4 26.3 15.5 20.2 28.0 26.9 15.6 20.4 28.6 27.4 16.5 21.7 28.8 28.0 17.3 22.9 28.9 28.6
74 12.0 16.5 24.0 22.9 11.5 16.1 24.0 22.8 11.0 15.8 24.0 22.7 11.2 16.4 23.4 22.7 11.4 17.0 22.9 22.7
71 - 13.0 20.6 19.5 - 12.1 19.9 18.8 - 11.1 19.3 18.1 - 11.1 18.1 17.4 - 11.0 17.0 16.7
68 - 9.6 17.2 16.1 - 8.0 15.9 14.7 - 6.4 14.6 13.4 - 5.7 12.8 12.1 - 5.1 11.0 10.7
