360101-XTG-B-0508
14 Johnson Controls Unitary Products
FIGURE 3 - UNIT DIMENSIONS
HIGH VOLTAGE
CONN. “ x " DIA.
KNOCKOUT
6
DRAIN “ NPTI
CONDENSATE
LOW VOLTAGE CONN.
“ DIA. KNOCKOUT
FRONT
CONDENSER
COIL
15
4
BACK
SIDE RETURN
AIR OPENING
SIDE SUPPLY
AIR OPENING
BOTTOM RETURN
AIR OPENING
15
2
1
1
1
15
BOTTOM SUPPLY
AIR OPENING
2
LOW VOLTAGE CONN.
“ DIA. KNOCKOUT
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
FRONT
ELECTRICAL/FILTER
SERVICE ACCESS
COMPARTMENT PANEL
(OVERALL)
(OVERALL)
4
1
2
UNIT CONDENSATE
CONNECTION “ NPTI
(TRAP REQUIRED)
(OVERALL)
SIDE SUPPLY
AIR OPENING
SIDE RETURN
AIR OPENING
COMPRESSOR
SERVICE ACCESS
COMPARTMENT PANEL
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
REFRIGERANT
CONNECTIONS
“A” UNIT SIZE
DIMENSION
“A”
030 - 042 33
048 - 060 41
CLEARANCES
(Minimum)
Front 12"
Back 0"
Left Side (Filter Access) 24"
Right Side 24"
Below Unit 1 0"
Above Unit 2 36" (For Condenser
Air Discharge)
1 Units may be installed on combustible floors made from wood or class A,
B or C roof covering material.
2 Units must be installed outdoors. Overhanging structures or shrubs
should not obstruct outdoor air discharge outlet.
