Page 16
360101-XTG-B-0508
16
Johnson Controls Unitary Products
TYPICAL APPLICATIONS
FIGURE 5 - TYPICAL SLAB ON GROUND INSTALLATION
FIGURE 6 - TYPICAL ROOF CURB INSTALLATION
TO POWER SUPPLY
SUPPLY AIR
DUCT
RETURN AIR
DUCT
FIELD SUPPLIED
DISCONNECT SWITCH
LOCATED TO REAR OF UNIT
CONTROL WIRING
TO INDOOR
THERMOSTAT
SLAB ON GROUND
INSTALLATION
ROOF CURB
INSTALLATION
BOTTOM DUCT
SUPPLY AIR
DUCT
RETURN AIR
DUCT
CONTROL WIRING
TO INDOOR THERMOSTAT
TO POWER SUPPLY
FIELD SUPPLIED
DISCONNECT SWITCH
MOUNTED ON UNIT
ROOF CURB
INSTALLATION
REAR DUCT
