TABLE 5: COOLING CAPACITIES - 3-1/2 TON (DEB042)
TEMPERATURE
OF AIR ON
OUTDOOR COIL
AIR ON INDOOR COIL
1,050 CFM 1,225 1,400 1,575 1,750
WB °F WB °F WB °F WB °F WB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
40.7 39.0 36.5 34.1 42.0 40.3 37.7 35.2 43.3 41.6 38.8 36.3 43.9 42.1 39.3 36.8 44.4 42.6 39.8 37.2
Total Power
Input kW
4.09 3.82 3.77 3.75 4.16 3.89 3.83 3.81 4.23 3.95 3.90 3.88 4.38 4.10 4.04 4.02 4.54 4.25 4.18 4.16
Sen
s
ib
le Capacit
y
MBH
1
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity
En
te
ri
n
g
D
ry
Bu
lb
°
F
86 23.8 31.3 36.5 34.1 26.1 34.2 37.7 35.2 28.5 37.0 38.8 36.3 30.5 39.4 39.3 36.8 32.6 41.9 39.8 37.2
83 20.8 28.3 34.6 34.1 22.6 30.6 36.7 35.2 24.4 32.9 38.8 36.3 25.9 34.8 39.3 36.8 27.3 36.6 39.8 37.2
80 17.8 25.4 31.6 31.9 19.1 27.1 33.8 34.1 20.3 28.8 36.0 36.3 21.2 30.1 37.6 36.8 22.1 31.4 39.2 37.2
77 14.9 22.4 28.6 28.9 15.5 23.6 30.3 30.6 16.2 24.7 31.9 32.2 16.6 25.5 32.9 32.1 16.9 26.2 34.0 32.0
74 11.9 19.4 25.6 26.0 12.0 20.0 26.7 27.0 12.1 20.7 27.8 28.1 11.9 20.8 28.3 27.5 11.7 21.0 28.8 26.8
71 - 16.4 22.7 23.0 - 16.5 23.2 23.5 - 16.6 23.7 24.1 - 16.2 23.6 22.8 - 15.8 23.6 21.6
68 - 13.4 19.7 20.0 - 12.9 19.6 20.0 - 12.5 19.6 20.0 - 11.5 19.0 18.2 - 10.6 18.3 16.4
95 °F
Net Cap
MBH
38.7 36.7 34.0 32.7 40.1 38.1 35.2 33.9 41.6 39.4 36.5 35.2 42.1 39.9 36.9 35.6 42.6 40.3 37.4 36.0
Total Power
Input kW
4.16 4.06 3.96 3.98 4.23 4.13 4.03 4.05 4.30 4.19 4.10 4.11 4.44 4.33 4.23 4.25 4.59 4.47 4.37 4.39
Sensib
le C
a
pacit
y
MBH
1
E
n
te
ring Dry
Bu
lb °F
86 23.0 30.4 34.0 32.7 25.4 33.3 35.2 33.9 27.8 36.3 36.5 35.2 29.9 38.3 36.9 35.6 32.0 40.3 37.4 36.0
83 20.0 27.4 33.2 32.7 21.9 29.8 34.9 33.9 23.7 32.2 36.5 35.2 25.2 34.1 36.9 35.6 26.7 36.0 37.4 36.0
80 17.0 24.4 30.3 30.4 18.3 26.3 32.6 32.8 19.7 28.2 35.0 35.2 20.6 29.5 36.2 35.6 21.5 30.8 37.4 36.0
77 14.0 21.4 27.3 27.5 14.8 22.7 29.1 29.3 15.6 24.1 30.9 31.1 15.9 24.8 31.5 30.9 16.3 25.6 32.1 30.8
74 11.0 18.4 24.3 24.5 11.3 19.2 25.5 25.7 11.5 20.0 26.8 27.0 11.3 20.2 26.9 26.3 11.1 20.4 26.9 25.5
71 - 15.4 21.3 21.5 - 15.6 22.0 22.2 - 15.9 22.7 22.9 - 15.5 22.2 21.6 - 15.2 21.7 20.3
68 - 12.4 18.3 18.5 - 12.1 18.4 18.7 - 11.8 18.6 18.8 - 10.9 17.6 17.0 - 10.0 16.5 15.1
105 °F
Net Cap
MBH
36.2 33.9 30.8 31.2 37.6 35.1 32.0 32.4 38.9 36.4 33.1 33.6 39.4 36.8 33.5 34.0 39.9 37.3 33.9 34.4
Total Power
Input kW
4.40 4.28 4.20 4.22 4.47 4.35 4.27 4.29 4.54 4.42 4.34 4.35 4.69 4.57 4.48 4.50 4.84 4.71 4.63 4.64
S
ensible
Cap
a
city
MBH
1
Ent
e
ri
ng Dry
Bul
b
°
F
86 22.4 29.3 30.8 31.2 24.8 32.1 32.0 32.4 27.3 34.9 33.1 33.6 29.3 36.1 33.5 34.0 31.4 37.3 33.9 34.4
83 19.4 26.3 30.5 31.2 21.3 28.8 31.8 32.4 23.2 31.3 33.1 33.6 24.7 33.2 33.5 34.0 26.2 35.1 33.9 34.4
80 16.4 23.3 27.8 28.8 17.7 25.3 30.1 31.2 19.1 27.2 32.4 33.6 20.0 28.6 33.1 34.0 21.0 29.9 33.9 34.4
77 13.4 20.3 24.8 25.8 14.2 21.7 26.5 27.6 15.0 23.1 28.3 29.5 15.4 23.9 28.5 29.3 15.8 24.7 28.7 29.1
74 10.4 17.3 21.8 22.8 10.7 18.2 23.0 24.1 10.9 19.0 24.2 25.4 10.7 19.3 23.8 24.7 10.6 19.5 23.5 23.9
71 - 14.3 18.8 19.8 - 14.7 19.4 20.6 - 15.0 20.1 21.3 - 14.6 19.2 20.0 - 14.3 18.3 18.7
68 - 11.4 15.8 16.8 - 11.1 15.9 17.0 - 10.9 16.0 17.2 - 10.0 14.5 15.4 - 9.1 13.1 13.5
115 °F
Net Cap
MBH
33.8 31.1 27.7 29.8 35.0 32.2 28.8 30.9 36.3 33.4 29.8 32.0 36.7 33.8 30.1 32.3 37.2 34.2 30.5 32.7
Total Power
Input kW
4.64 4.51 4.44 4.46 4.71 4.58 4.51 4.53 4.78 4.65 4.58 4.59 4.94 4.80 4.73 4.75 5.09 4.96 4.88 4.90
Se
nsible Capa
c
ity
MB
H
1
E
n
te
ri
ng
D
ry
Bulb
°
F
86 21.7 28.3 27.7 29.8 24.2 30.8 28.8 30.9 26.7 33.4 29.8 32.0 28.8 33.8 30.1 32.3 30.9 34.2 30.5 32.7
83 18.7 25.3 27.7 29.8 20.7 27.8 28.8 30.9 22.6 30.3 29.8 32.0 24.2 32.3 30.1 32.3 25.7 34.2 30.5 32.7
80 15.7 22.3 25.3 27.1 17.1 24.3 27.5 29.5 18.5 26.3 29.8 32.0 19.5 27.7 30.1 32.3 20.5 29.1 30.5 32.7
77 12.7 19.3 22.3 24.1 13.6 20.7 24.0 26.0 14.4 22.2 25.7 27.9 14.9 23.0 25.5 27.7 15.3 23.8 25.3 27.5
74 9.7 16.3 19.3 21.1 10.0 17.2 20.4 22.5 10.3 18.1 21.6 23.8 10.2 18.4 20.8 23.0 10.1 18.6 20.1 22.3
71 - 13.3 16.3 18.1 - 13.7 16.9 18.9 - 14.0 17.5 19.7 - 13.7 16.2 18.4 - 13.4 14.8 17.1
68 - 10.3 13.3 15.2 - 10.1 13.4 15.4 - 9.9 13.4 15.6 - 9.1 11.5 13.7 - 8.2 9.6 11.9
125 °F
Net Cap
MBH
31.4 28.3 24.6 28.3 32.5 29.3 25.5 29.3 33.6 30.4 26.4 30.3 34.0 30.7 26.7 30.7 34.5 31.1 27.1 31.1
Total Power
Input kW
4.9 4.7 4.7 4.7 4.9 4.8 4.7 4.8 5.0 4.9 4.8 4.8 5.2 5.0 5.0 5.0 5.3 5.2 5.1 5.2
Sen
s
ib
le Capacit
y
MBH
1
En
te
ri
n
g
D
ry
Bu
lb
°
F
86 21.1 27.2 24.6 28.3 23.6 29.6 25.5 29.3 26.1 31.9 26.4 30.3 28.3 31.5 26.7 30.7 30.4 31.1 27.1 31.1
83 18.1 24.2 25.0 28.3 20.0 26.8 25.7 29.3 22.0 29.4 26.4 30.3 23.6 31.3 26.7 30.7 25.2 33.3 27.1 31.1
80 15.1 21.3 22.8 25.5 16.5 23.3 25.0 27.9 17.9 25.3 27.2 30.3 19.0 26.7 27.1 30.7 20.0 28.2 27.1 31.1
77 12.1 18.3 19.8 22.5 13.0 19.7 21.4 24.4 13.9 21.2 23.1 26.3 14.3 22.1 22.5 26.1 14.8 23.0 21.9 25.9
74 9.1 15.3 16.8 19.5 9.4 16.2 17.9 20.8 9.8 17.1 19.0 22.2 9.7 17.4 17.8 21.4 9.5 17.7 16.6 20.7
71 - 12.3 13.8 16.5 - 12.7 14.4 17.3 - 13.1 14.9 18.1 - 12.8 13.2 16.8 - 12.5 11.4 15.5
68 - 9.3 10.8 13.5 - 9.1 10.8 13.8 - 9.0 10.8 14.0 - 8.1 8.5 12.1 - 7.3 6.2 10.2
