TABLE 1: PHYSICAL DATA
MODELS
DEB
030
036
042
048
060
EVAPORATOR
BLOWER
CENTRIFUGAL BLOWER (Dia. x Wd. in.)
10 X 8
10 x 8
11 X 10
11 x 10
11 x 10
FAN MOTOR HP
½
1
EVAPORATOR
COIL
ROWS DEEP
2
2
2
2
3
FINS PER INCH
15
15
15
13
16
FACE AREA (Sq. Ft.)
4.38
4.38
4.38
5.62
5.26
CONDENSER
FAN
PROPELLER DIA. (in.)
22
22
22
22
22
FAN MOTOR HP
1/4
1/4
1/4
1/4
1/4
NOM. CFM TOTAL
2,400
2,400
2,400
2,800
2,800
CONDENSER
COIL
ROWS DEEP
1
1
1
1
1
FINS PER INCH
20
18
16
13
20
FACE AREA (Sq. Ft.)
8.3
8.3
11.7
16.4
16.4
CHARGE
REFRIGERANT 22 (lbs./oz.)
3 / 13
3 / 10
4 / 8
5 / 15
5 /15
FILTER
FACE AREA (Sq. Ft.) / Qty. / Size
2.14 / 2 / 14" x 22"
COMPRESSOR
HERMETIC, QTY. = 1 (Type)
Recip.
Recip.
Recip.
Scroll
Scroll
3
4
3
4
3
4
TABLE 2: RATINGS - ARI
Model DEB
Cooling Capacity
1
80/67-95 °F
Sound Rating
2
(decibels)
Electric Heat
Nom. Capacity
KW
(single phase)
Electric Heat
Nom. Capacity
KW
(three phase)
MBH
EER
030
29.0
8.9
79
5.0, 7.5, 10.0, 15.0
-
036
35.2
8.7
81
5.0, 7.5, 10.0, 15.0
10.0, 15.0
042
40.5
9.4
83
5.0, 7.5, 10.0, 15.0
10.0, 15.0
048
46.5
8.8
81
10.0, 15.0, 20.0, 25.0
10.0, 15.0, 20.0, 25.0
060
59.0
8.8
79
10.0, 15.0, 20.0, 25.0
10.0, 15.0, 20.0, 25.0
1. Certified in accordance with the Unitary Small Equipment certification program, which is based on ARI Standard 210/
240.
2. Rated in accordance with ARI Standard 270.
